Advantage of Hydraulic Machine :-
- Better / Strong clamping
- More reliable performance
- Less maintenance
- Saving of electricity (No use of air compressor)
Machining diameter: According to customer’s requirement (60 MM/ 80 MM / 100 MM / 120 MM).
- Most popular in India
- Trouble-Free operation and controls
- Pipe clamping and feeding is hydraulic
- High-speed parting solution with accuracy
- Dry cutting make machine environment friendly
- Very competitive and cost effective
- Automatic feeding and cutting reduce your labour cost
- One operator can manage two machine with no trouble
- Parting machine able to do two operation at the same time
Machine has various spares, which is being provided by us to run machine smoothly.
Technical Details of Hydraulic Parting Machine Dia : 60 MM
- Tube dia range, 35 to 62mm
- Max length of parting piece, 100mm
- Max rpm of spindle, 1,200
- Feeding speed, X-direction, 0 to 12 m/minute
- Feeding speed, Y-direction, 0 to 24 m/minute
- Main moter rate, 3kw
- Hydraulic pump motor rate, 0.75kw
- Machine dimension, 1,600 x 1,000 x 1,500 mm
- Machine weight, 1,160 kg
- Tube End Pc :- 70 / 80 mm
- Capacity
- 62 mm Dia :- approx 6000 pcs. in eight hours
- 35 mm Dia :- approx 8000 pcs. in eight hours
